When optimizing the ICSI procedure, it is important to choose the exact micropipettes best suited to your needs.

Production Details
Order Informantion

Production Details

  • It is intended for use in the field of assisted reproductive techniques for Intracytoplasmic Sperm Injection (ICSI).
  • Spermatozoa are aspirated into the ICSI pipette and injected into the oocyte using a micromanipulator.
  • It has a pointed tip design that provides controlled entry while minimizing oocyte degeneration.
  • Tip angle  can be further customized by diameter and tip to elbow length..
  • Thanks to the optimal tip to elbow length, it offers control of motion inside the pipette. Helps to aspirate a large number of sperm at the same time and administer sperm injection in a controlled manner.  Features a unique tapered tip  design to minimize oocyte degeneration.
  • Facilitates easy and non-traumatic sperm-oocyte penetration.
  • There are 10 packs of ICSI Pipettes in a box.
  • Our products have been tried and tested hundreds of times by end users during optimization process.

Order Informantion

Referance Number Tip Bending Angle (°) Total Length(mm) Inner Diameter (µm) Tip Length(µm)
EMICSI01 30 50-65 4 11 – 13
EMICSI02 35 50-65 4 11 – 13
EMICSI03 30 50-65 5 11 – 13
EMICSI04 30 50-65 4 – 4,5 11 – 13
EMICSI05 0 50-65 4 – 4,5 11 – 16
EMICSI06 15 50-65 4 – 4,5 11 – 16
EMICSI07 20 50-65 4 – 4,5 11 – 16
EMICSI08 30 50-65 4 – 4,5 11 – 16
EMICSI09 35 50-65 4 – 4,5 11 – 16
EMICSI10 25 50-65 4 – 4,5 11 – 16
EMICSI11 0 50-65 4 – 4,5 17 – 20
EMICSI12 20 50-65 4 – 4,5 17 – 20
EMICSI13 15 50-65 4 – 4,5 17 – 20
EMICSI14 30 50-65 4 – 4,5 17 – 20
EMICSI15 35 50-65 4 – 4,5 17 – 20
EMICSI16 25 50-65 4 – 4,5 17 – 20
EMICSI17 35 50-65 5 – 6 12 – 15
EMICSI18 20 50-65 5 – 6 12 – 15
EMICSI19 0 50-65 5 – 6 12 – 15
EMICSI20 15 50-65 5 – 6 12 – 15
EMICSI21 25 50-65 5 – 6 12 – 15
EMICSI22 30 50-65 4 – 5 13 – 16
EMICSI23 35 50-65 4 – 5 13 – 16
EMICSI24 0 50-65 4 – 5 13 – 16
EMICSI25 15 50-65 4 – 5 13 – 16
EMICSI26 20 50-65 4 – 5 13 – 16
